What is an idler frame?
It is the welded structure that mounts the idler rolls at the correct spacing and trough angle and bolts to the conveyor stringers.
ALN · Frames
Offset Self-aligning Frame
偏置调心支架
An idler frame for self-aligning sets, engineered to keep the training rollers square to the belt so the centring action actually happens.
- SKU prefixFRAMES-ALN
- MOQ100 pcs
- Lead time1 month
- StandardALN
Configure & add to inquiry cart
Choose the specs for your application. We will reply with pricing, FOB and lead time for your selection.
Current SKU: FRAMES-ALN
Overview
Offset Self-aligning Frame at a Glance
Self-alignFunction
Offset bendDesign
BoltedBuild
ISO 9001 / MACertified · ALN
Usage
Usage
Offset Training Bracket — a frame bracket that holds the training idlers in a deliberately offset arrangement so any belt drift steers the belt back toward centre. It is the physical mounting that lets self-aligning idlers do their job on long or shifting-load lines.
Operating conditions
Operating conditions
| Working temperature | Ambient service range (-20 °C to +40 °C); the coating protects the steel, stainless for aggressive sites. |
|---|---|
| Dusty environment | Suitable — all-steel structure with no bearings or seals to contaminate |
| Moisture & water | Suitable — hot-dip galvanized or stainless frames for outdoor, port and washdown service |
| Corrosive environment | Powder-coated for ordinary acid or alkali · Galvanized for coastal and semi-outdoor · Stainless for high-salinity and high-humidity sites |
| Certification | MA coal-mine safety certified versions available — confirm the certified SKUs for your project |
| Outdoor use | Suitable — coated and stainless options for coastal and weathering service |
Technical overview
Idler frames and structures hold the rolls in alignment and transfer belt loads into the foundations. HBXM supplies carrying, return and training frames in galvanized or painted steel, cut and drilled to your belt width and trough angle.
How do I specify a frame for my conveyor?
Give us belt width, trough angle, idler arrangement and stringer spacing; we cut and drill to match so installation is bolt-on.
Are frames supplied pre-assembled?
We can ship loose sets for container savings or pre-welded frames for faster site erection, depending on your logistics.
Galvanized or painted steel?
Galvanizing suits outdoor and corrosive sites; painted frames are fine for enclosed or dry plants and cost less.
Highlights
Features
Bolted structure
Field-assembled bents for easy install and line changes.
Self-aligning
Free-pivot set auto-centers the belt as it drifts.
Aligned idlers
Machined seats keep idlers square to the belt.
Structural steel fabrication
Channel and box sections built to drawing.
Bolted or welded build
Field-adjustable or fixed assembly per site need.
Accurate hole pattern
Jig-drilled for fast, aligned roller mounting.
Quality
1
Weld integrity
Welds inspected for load-path continuity.
2
Dimensional accuracy
Holes and spans match the approved drawing.
3
Material certification
Steel grade verified per order.
4
Finish options
Coatings for weather and corrosion exposure.
